1% Instant Discount on Bank Transfer. SPECIFICATIONS (PAX-I PLUS : PCH-30CS)
* The specifications are subject to change without prior notice.
| Function | Pano + Ceph | Weight | With Ceph unit | 120kg (264.5 lbs. – without Base) |
|---|---|---|---|---|
| Scan Time | Pano : Normal 10.4 sec / HD 14 sec Ceph : 1.9Â sec / 3.9Â sec |
|||
| Focal Spot | 0.5mm (IEC60336) | 160kg (352.7lbs. – with Base) | ||
| Tube Voltage / Current | 60~90 kV / 4-10 mA | |||
| Gray Scale | 14 bit | Dimensions | With Ceph unit | 1930mm(L) x 1200mm(W) x 2300mm(H) |
| SELECTION | ARCH | EXAMINATION MODE |
|---|---|---|
| PANO EXAMINATION | Narrow / Normal Wide / Child | Standard / Right / Front / Left |
| Orthogonal | Orthogonal Standard / Right / Front / Left Bitewing Standard / Right / Front / Left | |
| SPECIAL EXAMINATION | Normal | TMJ LAT Open / Close TMJ PA Open / Close Sinus LAT / PA |
| Rapid Ceph |
|
|---|---|
| User friendly EzDent-i software |
|
MINIMIZE MOTION ARTIFACTS WITH RAPID CEPH TECHNOLOGY
The next step in cephalometric technology, Vatech’s new Rapid Ceph minimizes motion artifacts and enables faster diagnostic workflow while providing the highest quality digital images.
GREAT CLINICAL CARE WITH RAPID CEPH TECHNOLOGY
